UTP CAT6a Cable: Aston Cable's High Performance Copper RG6 Coaxial Cable

When it comes to cabling solutions, Aston Cable aims to exceed industry standards while offering the best value. A prime example of our commitment to quality is our high-performance UTP CAT6a Cable - formerly known as the Copper RG6 Coaxial Cable. Our UTP CAT6a Cable, spanning a generous 100 meters, is specifically designed for CATV Antennas. This cable highlights a 100% OFC Barecopper conductor, which sets it apart from the CCS conductor cables. It promises exceptional attenuation performance with lower loss, making it a favored choice amongst our clientele. Why should you choose our UTP CAT6a Cable? Apart from its primary attributes, it also offers superior data transmission, ensuring continuous and unhampered communication flow. This cable boosts the efficiency of your network and minimizes the risk of data loss. Previously known as the Copper RG6 Coaxial cable, this UTP CAT6a Cable still integrates all the features that made it an industry favorite. Aston Cable continuously strives to elevate the quality of its products, and with this cable, we've taken a significant step in that direction.

· Short Description

- OFC 100% Bare copper conductor cable coaxial

• Copper coaxial cable RG6 has much better attenuation performance and lower loss than CCS conductor. Especially in CATV system and antenna.

- MOQ:30KM

---

· Specification





· Quick detail

Conductor ：18 AWG Copper

Stranding ： Solid

Insulation ： Material Gas Injected Polyethylene

Insulation Thickness ： 0.180” Nominal

Number of Conductors ： 1 Center Conductor

Shield  ： 100% Al Foil + 61% CCA. Braid (36 AWG)

Jacket Material ： PVC

Cable Diameter  ：  0.265'' Nominal

Cable Weight ： 35 lbs/1000 ft Nominal



· Description

100% copper conductor coaxial cable rg6 support good signal transmission, longer service cable life, fewer after-sales issues, this cable is good choose for customers who want better quality and market.



· Attenuation

5 MHz - 5 MHz - 1.7 dB/100m,

50 MHz - 5.0 dB/100m,

200 MHz - 8.7 dB/100m,

400 MHz - 12.8 dB/100m,

800 MHz - 18.0 dB/100m,

1000 MHz - 19.8 dB/100m,

1350 MHz - 23.8 dB/100m,

1750 MHz - 28.0 dB/100m,

2150 MHz - 31.4 dB/100m,

3000 MHz - 38.0 dB/100m



· Product Display

Choose our UTP CAT6a Cable - the high-performance Copper RG6 Coaxial Cable, and experience a noticeable improvement in your network's performance. Trust us to offer the best cabling solutions that are not only effective but also offer great value for your investment. Explore the advantages of a cable that offers better attenuation performance, lower loss, and high-quality data transmission. Choose Aston Cable's UTP CAT6a Cable today. We're here to cater to all your cabling needs, with a promise of quality and durability.
