Double shield RG11 coaxial cable CCS conductor

· Short Description

- The RG11 cable is a coaxial radio guide cable with a protective wrapping around it
- RG11 is a thicker version that covers a larger area
- RG11 Cable is a much thicker cable than RG6 RG59 Cable
- Long-range signal strength, for outdoor or unusual applications

- MOQ:30KM

Quick inquiry Datasheet

Product Detail

Product Tags

· Product Details

Place of Origin:	China
Brand Name:	ASTON or OEM
Certification:	SGS CE ROHS ISO9001
Coaxial Cable Daily Output:	200KM

· Payment & Shipping

Minimum Order Quantity：	30km
Price（usd）	Negotiate
Packaging Details：	Normal export packaging
Supply Ability ：	25000KM/Per year
Delivery Port：	Ningbo

· Specification

Product Name:	RG11 Coaxial cable	Jackets:	PVC,PE for outdoor
Color:	Black	Conductor:	1.63mm 14AWG
Usage:	Radio guide cable	Logo:	OEM
Industrial Use:	Data transmission cable	Origin:	Hangzhou Zhejiang

· Quick detail

Cable Length 304.8 m | 1000 ft

Diameter Over Center Conductor, specific 0.0641 in per 1 strand

Diameter Over Dielectric 7.112 mm | 0.28 in

Diameter Over Jacket Tolerance ±0.008 in

Diameter Over Jacket, nominal 9.169 mm | 0.361 in

Diameter Over Shield (Braid) 8.179 mm | 0.322 in

Jacket Thickness 0.508 mm | 0.02 in

Jacket Thickness, minimum spot 0.406 mm | 0.016 in

Center Conductor Gauge 14 AWG

Inner Shield (Braid) Gauge 34 AWG

Capcitance	52.493 pF/m \| 16 pF/ft	Characteristic Impedance	75 ohm
Dielectric Strength, conductor to shield	4000 Vdc	Conductor dc Resistance	36.089 ohms/km \| 11 ohms/kft
Nominal Velocity of Propagation (NVP)	84 %	Jacket Spark Test Voltage	5000 Vac
Structural Return Loss Test Method	100% Swept Tested	Structural Return Loss	15 dB @ 1000–3000 MHz \| 20 dB @ 5–1000 MHz

· Description

RG11 is a 14-gauge wire, a higher gauge than other video cables, giving it more room to transfer signal. RG11 cable provides 3Ghz frequency for CATV, HDTV, TV antenna, and video distribution

· Product Display
