Twisted Pair Fire Alarm Cable: Aston Cable's CY Flexible Control Solution

Aston Cable's CY Flexible Control Cable, our innovative take on Twisted Pair Fire Alarm Cable, is designed to revolutionize the way you perceive safety and control. These cables, characterized by their number coded control and connection makeup, come with a robust tinned copper braid screen, ensuring efficient functionality across the board. The CY Flexible Control Cable, otherwise known as the Twisted Pair Fire Alarm Cable, stands out in its category due to its unique ability to deliver superior flexibility and control. It’s robust yet flexible construction enables it to accommodate a wide range of applications – from control systems to security alarms, making it an exceptionally versatile product. The unique composition of our CY Flexible Control Cable, notably its tinned copper braid screen, provides the cable with an added layer of protection. It not only safeguards the cable from potential external damage but also ensures consistent performance. This is particularly crucial in alarm systems where cable reliability can mean the difference between safety and danger.

· Short Description

- CY cables are number coded control and connection cables with tinned copper braid screen. EMC compliant and space saving installation due to small cable diameters suitable for flexible use and fixed installation.

CY cables are suitable for flexible use and fixed installation for medium mechanical use. They are for use in dry, damp and wet rooms. They may only be installed outdoors with UV protection and in observation of the temperature range generally resistant against acids, caustics solutions and certain oils. CY cables are used as supply and interconnecting cable for controlling machine tools, production lines, control equipment on conveyors, also for use in measuring regulating and computer units. Suitable for free movement without forced guidance and tensile stress.

Conductor: Class 5 flexible annealed plain copper conductor

Number of Conductors: 2/3/4/5/7

Insulation:

CY PVC: PVC (Polyvinyl Chloride)

CY LS0H: XPLE (Cross-Linked Polyethylene)

Seath:

CY PVC: PVC (Polyvinyl Chloride)

CY LS0H: LSZH

- MOQ：30KM

---

· Specification





· Quick detail

Technical Data

Conductor : Bare copper, fine wire strand in accordance to IEC 60 228 that is VDE 0295, class 5

Core Insulation : PVC compound TI1 in accordance to VDE 0207

Identification : In according to VDE 0293, black cores with white numbers with green/yellow ground conductor

Braid : Tinned copper wire braid

Outer Sheath : Grey PVC compound TM2 in according to VDE 0207 Grey RAL 7001

Nominal Voltage : 300 / 500 V

Test Voltage : 3,000 V AC

Temperature Range : For flexible use -5 up to +70°C maximum conductor temperature

Fixed installation -40 up to +80°C maximum conductor temperature

Minimum bending radius : Fixed installation 12.5 × cable diameter

Flame retardant : In according to IEC 60 332.1 resp. VDE 0472 part 804

EC directive : This cable confirms to ECD 73 / 23 / EEC (low voltage directive)



· Description

Specification Table

Reel of 50M

Desription	Number cores*cross sectional area(mm2)	Outdoor diameter	Weight kg/km
Cable CY, 3 core,0.5mm	CY 3G0.5	6.1	59
Cable CY, 4 core,0.5mm	CY 4G0.5	6.5	71
Cable CY, 5 core,0.5mm	CY 5G0.5	7.0	86
Cable CY, 7 core,0.5mm	CY 7G0.5	7.5	105
Cable CY, 3 core,0.75mm	CY 3G0.75	6.5	68.7
Cable CY, 4 core,0.75mm	CY 4G0.75	7.0	85.5
Cable CY, 5 core,0.75mm	CY 5G0.75	7.7	102.4
Cable CY, 7 core,0.75mm	CY 7G 1.0	8.3	127.4
Cable CY, 3 core,1.0 mm	CY 3G 1.0	6.8	81.6
Cable CY, 4 core,1.0 mm	CY 4G 1.0	7.3	96.9
Cable CY, 5 core,1.0 mm	CY 5G 1.0	8.1	122
Cable CY, 7 core,1.0 mm	CY 7G 1.0	8.8	146.8

· Product Display

Aston Cable takes pride in delivering the highest standards of quality and safety with our CY flexible control cables. Our Twisted Pair Fire Alarm Cable represents a combination of uncompromised security and advanced technology. This cable is designed to meet the most stringent safety standards, ensuring the peace of mind that our consumers value. In conclusion, the CY flexible control cable is not just a product; it's a promise of safety, flexibility, and unparalleled control. Its unique features and advantages make it a stellar choice for a myriad of applications, making it a must-have item in an ever-evolving market where reliability and flexibility are key. Discover the difference with Aston Cable's CY Flexible Control Cable - your trusted Twisted Pair Fire Alarm Cable solution.
